ROOF GARDEN DRAIN CELL

Name: ROOF GARDEN DRAIN CELL
Brand: CIVILIZE MART
Price: 30.0 INR
Availability: InStock

Price 30.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Square Foot

ROOF GARDEN DRAIN CELL Specification

Thickness
20 mm

Diameter
Grid Cell: Approx. 30 mm

Purity
100% Virgin PP Material

Form
Modular Cell Panel

Load Capacity
Up to 120 t/sqm

Application
Roof Gardens, Landscaped Podium Decks, Planter Boxes, Drainage Layer for Terraces

Material Grade
UV Stabilized Virgin Polypropylene

Machines Type
Manual Installation

Features
Chemically Inert, Waterproof, Lightweight, Non-Toxic, Resistant to Microbial Growth

Installation Type
Interlocking, Laid Loose

Color
Black

Usage
Drainage Layer in Roof Gardens, Terraces, Planters, Green Roofs

Product Type
Drain Cell

Main Material
Polypropylene (PP)

Surface Treatment
None / Natural

Size
500 mm x 250 mm x 20 mm

Weight
Approx. 1.2 kg/piece

Feature
High compressive strength, Lightweight, Durable, Reusable

Shape
Rectangular Grid

Connection System
Snap/Lock Interlocking Design

Temperature Resistance
-30C to 120C

Flow Rate
27 L/min

Resistance
UV, Corrosion, Rot, Fungus

Water storage capacity
0.9 liter/piece

Eco-Friendliness
Recyclable Material

Compressive Strength
> 150 t/m2

Open area
Approx. 80%

ROOF GARDEN DRAIN CELL Trade Information

Minimum Order Quantity
1 Square Foot

Delivery Time
1 Days

About ROOF GARDEN DRAIN CELL

91 000 74051 Drainage cells are lightweight, interlocking modular units, typically made from recycled polypropylene, designed to create a crucial void space beneath surfaces for efficient sub-surface water management. This interconnected network allows water to flow horizontally towards drainage outlets, preventing waterlogging in green spaces, reducing hydrostatic pressure against structures like retaining walls and basements, and facilitating stormwater runoff in paved areas. Their high compressive strength supports overlying layers, while their ease of installation and environmental benefits, such as the use of recycled materials and contribution to sustainable drainage systems, make them a versatile and valuable component in various landscaping and construction applications.

Efficient Water Management for Green Roofs

The ROOF GARDEN DRAIN CELL ensures superior drainage and water retention, storing up to 0.9 liters per piece. Its 80% open area grid efficiently channels excess water, preventing waterlogging and root damage in green spaces. This feature promotes healthier vegetation and sustainable rooftop gardens.

Durable, Lightweight, and Easy to Install

Constructed from UV-stabilized virgin polypropylene, the Drain Cell can withstand temperatures from -30C to 120C and features a high compressive strength of over 150 t/m2. Its modular, lightweight design with snap-lock interlocking makes installation quick and tool-free, suitable for various urban landscaping needs.

Eco-Friendly and Maintenance-Free Solution

Chemically inert and 100% recyclable, the Drain Cell is resistant to rot, corrosion, fungus, and microbial growth. With no surface treatment required, it offers a long-life, reusable drainage layer that reduces maintenance and supports environmentally conscious construction practices.

FAQ's of ROOF GARDEN DRAIN CELL:

Q: How is the ROOF GARDEN DRAIN CELL installed on rooftops or terraces?

A: Installation is straightforward thanks to its snap/lock interlocking design. The lightweight panels are laid loose over the waterproofing layer and locked together manually, with no specialized tools required. This speeds up application for roof gardens, planters, and podiums.

Q: What are the key benefits of using a drain cell under green roof areas?

A: The drain cell provides excellent drainage and water retention, protecting roots from waterlogging and promoting robust plant growth. Its high compressive strength supports heavy loads, while its modular nature allows flexibility in design and reuse. The product is lightweight, durable, eco-friendly, and requires minimal maintenance.

Q: Where can ROOF GARDEN DRAIN CELLS be applied besides roof gardens?

A: These drain cells are versatile and suitable for planter boxes, landscaped podium decks, terrace gardens, and as a drainage layer for various other green infrastructure projects. Their ability to handle substantial loads makes them ideal for urban landscaping applications.

Q: What is the water storage and flow capacity of each drain cell piece?

A: Each cell can store up to 0.9 liters of water and is designed with an open area of around 80%, enabling an efficient flow rate of 27 liters per minute. This ensures optimal drainage and promotes healthy root systems in planted areas.

Q: How does the product ensure long-term durability in outdoor conditions?

A: Made from UV-stabilized virgin polypropylene, the drain cell resists degradation from sunlight, temperature extremes (-30C to 120C), microbes, rot, fungus, and chemical exposure. Its material and design ensure that it remains effective and structurally sound over many years.

Q: Is the material used in the drain cell environmentally friendly and non-toxic?

A: Yes, the drain cell is produced from 100% virgin polypropylene which is both recyclable and non-toxic. It is chemically inert, waterproof, and does not leach harmful substances into the environment, supporting sustainable design practices.
