HDPE DOTTED DRAINAGE MATS

Name: HDPE DOTTED DRAINAGE MATS
Brand: CIVILIZE MART
Price: 30.0 INR
Availability: InStock

Price 30.0 INR/ Square Foot

Get a Price/Quote

MOQ : 1 Square Foot

HDPE DOTTED DRAINAGE MATS Specification

Color
Black

Installation Type
Laid on site - unrolled or cut to fit

Load Capacity
Up to 400 kPa compressive strength

Application
Basement walls, Roof gardens, Retaining walls, Foundation and podium waterproofing

Usage
Soil water drainage, sub-soil separation

Features
Flexible, Chemical & rot resistance, Lightweight

Material Grade
Virgin/UV stabilized HDPE

Purity
98% minimum HDPE

Machines Type
Extruded Sheet Forming

Diameter
Dimple height 8-20 mm

Thickness
8 mm (standard); other thicknesses available

Form
Sheet roll - Dimpled structure

Product Type
Drainage Mat

Main Material
High Density Polyethylene (HDPE)

Surface Treatment
Dotted/Textured

Size
2 m x 20 m roll (custom sizes available)

Weight
Approx. 800-1200 g/m2

Feature
Efficient water drainage, High compressive strength, Chemical resistance

Shape
Roll with dimpled (dotted) sheet

Tensile Strength
500 N/50 mm

Water Flow Rate
2.8 l/s/m at 2% gradient

Temperature Resistance
-30C to 80C

Permeability
100% impermeable to water, allows controlled drainage

Packaging
Rolls wrapped with stretch film

UV Stability
Superior with UV stabilized material

Elongation at Break
Approx. 60% - 100%

Fire Resistance
Self-extinguishing

Eco-Friendly
Recyclable material

Service Life
>25 years under normal conditions

HDPE DOTTED DRAINAGE MATS Trade Information

Minimum Order Quantity
1 Square Foot

Delivery Time
1 Days

About HDPE DOTTED DRAINAGE MATS

91 000 74051 Drainage cells are lightweight, interlocking modular units, typically made from recycled polypropylene, designed to create a crucial void space beneath surfaces for efficient sub-surface water management. This interconnected network allows water to flow horizontally towards drainage outlets, preventing waterlogging in green spaces, reducing hydrostatic pressure against structures like retaining walls and basements, and facilitating stormwater runoff in paved areas. Their high compressive strength supports overlying layers, while their ease of installation and environmental benefits, such as the use of recycled materials and contribution to sustainable drainage systems, make them a versatile and valuable component in various landscaping and construction applications.

Optimal Drainage and Structural Protection

HDPE Dotted Drainage Mats provide an efficient solution for managing soil water drainage and sub-soil separation. The dimpled design facilitates a consistent water flow rate of 2.8 l/s/m at a 2% gradient, protecting structures from water ingress and erosion. Their superior imperviousness ensures no water passes through the mat, making them ideal for safeguarding basement walls, roof gardens, and retaining structures.

Superior Durability in Diverse Conditions

Engineered for resilience, these mats feature remarkable temperature resistance (-30C to 80C), UV stability, and self-extinguishing fire resistance, ensuring longevity even in harsh Indian climates. The high-strength HDPE composition, coupled with a service life exceeding 25 years under normal conditions, delivers reliable performance for a wide range of projects.

FAQ's of HDPE DOTTED DRAINAGE MATS:

Q: How are HDPE Dotted Drainage Mats installed on site?

A: The mats are supplied in roll form, typically 2 m x 20 m, and are easily unrolled and laid directly onto the prepared surface. They can be cut to fit specific dimensions, ensuring seamless coverage for different applications. Installation is straightforward, requiring minimal specialized tools.

Q: What are the primary applications for these drainage mats?

A: HDPE Dotted Drainage Mats are widely used for drainage and waterproofing in basement walls, roof gardens, retaining walls, and foundations. Their robust design also makes them suitable for podium waterproofing and sub-soil separation, providing dependable moisture control and protection.

Q: When should I use HDPE Dotted Drainage Mats in my construction project?

A: These mats should be used whenever effective water drainage or structural waterproofing is needed, especially in areas prone to water accumulation or hydrostatic pressure. They are highly recommended for new builds, renovation projects, and landscape designs that demand long-term durability.

Q: Where can these mats be utilized beyond standard construction?

A: Apart from traditional foundation waterproofing, these mats can be adapted for use in landscaping, sports fields, retaining structures, green roofs, and any sub-surface environment requiring controlled drainage and soil separation.

Q: What benefits do HDPE Dotted Drainage Mats offer compared to other materials?

A: Unlike traditional drainage solutions, these mats are lightweight, flexible, and easy to handle. They deliver superior chemical and rot resistance, have a high compressive load capacity (up to 400 kPa), and remain resilient under extreme temperatures. Their impermeable design guarantees no water seepage, protecting the underlying structures effectively.

Q: How does the product ensure environmental sustainability?

A: Manufactured from recyclable, virgin HDPE, the mats are eco-friendly. Their long service life, minimal maintenance needs, and ability to be fully recycled support sustainable building practices.
