DRINAGE & FILLER BOARD - HDPE DIMPLE PROTECTION AND DRAINAGE BOARD

Name: DRINAGE & FILLER BOARD - HDPE DIMPLE PROTECTION AND DRAINAGE BOARD
Brand: CIVILIZE MART
Price: 139.0 INR
Availability: InStock

Price 139.0 INR/ Square Meter

Get a Price/Quote

MOQ : 1 Piece

DRINAGE & FILLER BOARD - HDPE DIMPLE PROTECTION AND DRAINAGE BOARD Specification

Surface Structure
Dimpled (stud)

Material
High-Density Polyethylene (HDPE)

Thickness
8 mm, 10 mm, 20 mm (custom thickness available)

Tensile Strength
> 450 N/50 mm

Color
Black

Type
Dimple Protection and Drainage Board

Density
0.94 g/cm3

Service Life
More than 30 years

Installation
Easy to cut and install

Dimple Height
8 mm, 10 mm, 20 mm

Water Absorption
< 0.2% by mass

Board Size
2 m x 20 m (custom sizes available)

Chemical Resistance
Excellent against most solvents, acids and alkalis

UV Resistance
High

Water Flow Capacity
2.1 l/s/m (for 8mm type)

Elongation at Break
> 50%

Temperature Resistance
-30C to +80C

Application
Waterproofing protection, drainage, and filtration

Compressional Strength
350 kPa - 600 kPa

DRINAGE & FILLER BOARD - HDPE DIMPLE PROTECTION AND DRAINAGE BOARD Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
500 Pieces Per Month

Delivery Time
1 Days

About DRINAGE & FILLER BOARD - HDPE DIMPLE PROTECTION AND DRAINAGE BOARD

91 000 74051 Dimple Board and high density Polyethylene (HDPE) Dimpled board. It is light weight, flexible, Strong, durable, Non-toxic, dimpled sheet board with dimple height of 08mm. It is impermeable to water and water vapour. It is used for protecting the water Proofing Membrane in basement walls.

Durability and Performance

Engineered from high-density polyethylene, our Dimple Protection and Drainage Boards exhibit remarkable durability in the face of extreme environmental conditions. With compressional strengths ranging from 350 to 600 kPa and negligible water absorption (<0.2% by mass), these boards maintain performance over decades. Their UV resistance and excellent chemical resilience further ensure prolonged efficacy in challenging construction environments.

Versatile Applications and Easy Installation

These boards are specially designed for waterproofing, drainage, and filtration applications. Their flexibility and ease of cutting simplify on-site modifications, while the dimpled surface ensures efficient water management. Suitable for a range of projects, from basement walls to green roofs, the boards can be customized in thickness and size-meeting the diverse needs of the construction industry.

FAQ's of DRINAGE & FILLER BOARD - HDPE DIMPLE PROTECTION AND DRAINAGE BOARD:

Q: How do you install HDPE Dimple Protection and Drainage Boards?

A: Installation is straightforward-cut the board to the required size using a utility knife, then lay it dimpled side down against the substrate. Secure the edges with appropriate fasteners, overlap any seams for continuity, and install according to the project's waterproofing system requirements.

Q: What are the primary benefits of using this drainage board?

A: The main benefits include exceptional durability, long service life (>30 years), strong water management due to its high flow capacity (2.1 l/s/m for 8mm), outstanding chemical and UV resistance, and ease of installation. Its robust structure protects waterproofing layers and enhances drainage efficiency.

Q: When should these boards be used in construction projects?

A: These boards are ideal during the waterproofing phase of construction, particularly when long-term drainage and protection are needed-such as in basements, retaining walls, plaza decks, or green roofs. Early installation protects structures from water ingress and foundation damage.

Q: Where can the HDPE Dimple Protection and Drainage Board be applied?

A: They can be applied in multiple environments: below-grade foundation walls, underground structures, tunnels, bridge abutments, and landscaped roofs. Their chemical and temperature resistance make them suitable for both residential and large-scale commercial projects.

Q: What is the process for customizing board size or thickness?

A: To customize the board's size or thickness, contact your authorized distributor, supplier, or service provider. Share your project's dimensions and specific requirements, and the manufacturer will provide tailored solutions to match your needs.

Q: How does its dimpled surface structure enhance drainage?

A: The dimpled or studded design creates continuous air gaps and channels that allow water to flow freely along the surface, effectively directing excess water away from the waterproofing membrane and minimizing the risk of seepage.

Q: What are the recommended usage and maintenance practices for these boards?

A: Once installed, the boards require minimal maintenance thanks to their chemical stability and weather resistance. Regular inspection of site drainage systems ensures optimal performance, but the HDPE material itself does not degrade under normal usage conditions.
