HDPE Corrugated Subsoil Drainage Pipe

Name: HDPE Corrugated Subsoil Drainage Pipe
Brand: CIVILIZE MART
Price: 349.0 INR
Availability: InStock

Price 349.0 INR/ Meter

Get a Price/Quote

MOQ : 1 Piece

HDPE Corrugated Subsoil Drainage Pipe Specification

Standard
IS 16098, DIN 4262, EN 13476

Water Permeability
Perforated or Non-Perforated options

Installation
Buried underground

Diameter Range
100 mm to 1000 mm

Chemical Resistance
Excellent

Connection Type
Socketed / Plain Ends / Couplers

UV Resistant
Yes

Wall Structure
Double wall corrugated

Material
High Density Polyethylene (HDPE)

Application
Subsoil drainage, Agriculture, Road and Highway drainage, Landfill drainage, Sports field drainage

Load Class
SN4 / SN8

Type
Corrugated Subsoil Drainage Pipe

Temperature Resistance
-40C to +60C

Color
Black with Yellow inner lining

Shape
Round / Corrugated

Length
6 m / 12 m standard or as per requirement

HDPE Corrugated Subsoil Drainage Pipe Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
500 Pieces Per Month

Delivery Time
1 Days

About HDPE Corrugated Subsoil Drainage Pipe

91 000 74051 HDPE Corrugated Drainage Pipes are lightweight, durable, and flexible pipes made from High-Density Polyethylene (HDPE), specially designed for underground water drainage and subsoil water management. The corrugated (ribbed) outer surface provides high strength and load resistance, while allowing flexibility for easy installation.

These pipes are widely used in construction, agriculture, landscaping, and infrastructure projects to safely remove excess water and prevent waterlogging, seepage, and soil erosion.

Superior Material and Structure

Fabricated from high-density polyethylene (HDPE), this double-wall corrugated pipe offers outstanding durability and flexibility. Its design ensures superior resistance to physical stress, chemicals, and harsh weather, making it a reliable choice for both light and heavy-load drainage projects in challenging environments.

Versatile Applications Across Industries

Ideal for a variety of applications, these pipes are extensively used for subsoil drainage in agriculture, road and highway construction, landfill management, and sports field drainage. Their adaptability and compliance with multiple standards guarantee consistent performance in diverse underground drainage projects.

User-Friendly Installation and Maintenance

Engineered for straightforward installation, the pipes can be connected via sockets, plain ends, or couplers, and laid underground in long lengths (6 or 12 meters). The perforated or non-perforated options support tailored water permeability, reducing maintenance with minimal risk of blockages.

FAQ's of HDPE Corrugated Subsoil Drainage Pipe:

Q: How is the HDPE corrugated subsoil drainage pipe installed underground?

A: The pipe is typically laid in a pre-dug trench, with connections made via sockets, plain ends, or couplers. Its lightweight nature and long standard lengths (6 or 12 meters) allow for efficient installation, and it can be covered with soil after positioning to function as part of a continuous underground drainage system.

Q: What types of drainage projects is this pipe suitable for?

A: This pipe is well-suited for subsoil drainage in agriculture fields, road and highway projects, landfill sites, and sports fields. Its robustness and compliance with IS 16098, DIN 4262, and EN 13476 standards make it versatile for new constructions or infrastructure upgrades.

Q: When should I use perforated versus non-perforated pipe variants?

A: Perforated pipes are recommended for areas where subsoil water needs to be collected and directed away, such as agricultural fields or sports grounds. Non-perforated pipes are ideal for situations where you require water to be transported without infiltration or exfiltration, such as in culverts or closed drainage lines.

Q: Where can I source HDPE corrugated subsoil drainage pipes in India?

A: As a distributor, service provider, supplier, and trader in India, you can obtain these pipes directly from specialized vendors who offer various diameters and lengths, ensuring you receive products meeting local and international standards suited to your project's requirements.

Q: What benefits does the double wall corrugated structure offer?

A: The double wall corrugated structure provides high mechanical strength, excellent load-bearing capacity (SN4 / SN8), and ensures long-term durability. The inner smooth yellow lining also enhances water flow and allows for easy inspection with CCTV tools if required.

Q: How does the pipe perform in harsh environments or extreme weather conditions?

A: With a temperature resistance range from -40C to +60C and strong UV and chemical resistance, the HDPE corrugated pipe maintains reliable performance under variable environmental conditions, making it ideal for outdoor and buried installations.
