CYH 500 SINGLE COMPONENT PU FOAM EPOXY GROUT

Name: CYH 500 SINGLE COMPONENT PU FOAM EPOXY GROUT
Brand: CIVILIZE MART
Price: 8717.0 INR
Availability: InStock

Price 8717.0 INR/ Kilograms

Get a Price/Quote

MOQ : 1 Kilograms

CYH 500 SINGLE COMPONENT PU FOAM EPOXY GROUT Specification

Usage & Applications
Waterproofing, Crack Injection, Leak Sealing, Structural Repair

Grade Standard
Industrial Grade

Purity
> 99%

Flash Point
> 200C

Water Absorption
< 0.2%

Packaging Size
20 kg / 25 kg Barrel

Chemical Form
Foam Liquid

Type
Single Component PU Foam Epoxy Grout

Material
Polyurethane (PU), Epoxy

Thickness
Customizable

Density
0.02 Gram per cubic centimeter(g/cm3)

Color
Light Yellow

Width
As Required

Length
Customized

VOC Content
Low

Solubility
Insoluble in Water

Compressive Strength
> 45 MPa

Hardness (Shore A)
> 65

Application Method
Manual or Mechanical Injection

Shelf Life
12 Months (Unopened)

Storage Conditions
Store in Cool, Dry Place

Tack Free Time
Within 30 Minutes

Toxicity
Non-Toxic after Curing

Elongation at Break
> 200%

Viscosity
200-300 mPas at 25C

Curing Time
15-30 Minutes

CYH 500 SINGLE COMPONENT PU FOAM EPOXY GROUT Trade Information

Minimum Order Quantity
1 Kilograms

Delivery Time
1 Days

About CYH 500 SINGLE COMPONENT PU FOAM EPOXY GROUT

91 000 74051 CYH-500 is a single-component hydrophobic polyurethane grout that, upon contact with water, expands into a closed-cell rubber-like foam. It is used to stop water leaks, fill small cracks, joints, honeycombs, and voids in concrete structures. It cures into a constant volume material that neither shrinks nor swells. Ideal for water tanks, tunneling, sewage, basements, and other structures exposed to moisture.
Uses / ApplicationsFilling and sealing cracks, joints, and honeycombs in concrete Pipe intrusions, leak points in pipe penetrations Water tanks, sewage, tunnels, dams, manholes Concrete defects in both dry and wet concrete surfaces
FAQ (Questions & Answers)
Q1. How fast does CYH-500 set / react?Gel time is ~110 seconds (25 C) when resin:water is 2:1 ratio. Induction is ~15 seconds. Q2. Will it shrink after curing?No. It cures to a constant volume, with no shrinkage or swelling after cure. Q3. Can it be used under flowing water / wet concrete?Yes it's hydrophobic and bonds well to wet surfaces. Negative-side application also possible. Q4. What is its expansion capability?When mixed in resin:water ratio ~10:1, expansion up to ~27-30 (2700 %) is possible.
Q5. What conditions are needed (temperature, surface)?Substrate & ambient temperature should be 5 C. Store product in dry, cool place. Apply on clean surfaces. Work in moderate conditions for better performance. Q6. How much will 20 kg cover / fill?Depends entirely on crack size, depth, width, amount of water mixed. Because it expands, a small volume can fill larger voids. As a rough estimate, for very fine cracks maybe few linear metres; for cavities depends on expansion ratio and injection methodology. Better to do a mock-trial.Q7. Approx price?Please visit CIVILIZEMART

Exceptional Performance and Quick Application

CYH 500 PU Foam Epoxy Grout is formulated to deliver rapid sealing and structural reinforcement. Its fast curing time (within 30 minutes) and high compressive strength ensure efficiency and durability. Whether tackling waterproofing or structural repairs, this single component solution simplifies the process while producing robust results.

Versatile Uses and Flexible Application Methods

From crack injection to large-scale leak sealing, CYH 500 adapts to complex project requirements. Its manual or mechanical injection compatibility ensures flexibility for contractors, while its foam liquid form penetrates deep into fractures, guaranteeing comprehensive coverage and reliability.

Safe, Sustainable, and Reliable

Non-toxic after curing and with a low VOC content, CYH 500 meets stringent environmental standards. Its long shelf life and resistance to water absorption (<0.2%) contribute to superior long-term performance, making it a safe choice for industrial-grade projects across India.

FAQ's of CYH 500 SINGLE COMPONENT PU FOAM EPOXY GROUT:

Q: How is CYH 500 Single Component PU Foam Epoxy Grout applied for repair or sealing jobs?

A: CYH 500 can be injected either manually or mechanically into cracks, leaks, or structural voids. Its low viscosity allows easy flow and deep penetration, ensuring effective filling and sealing of the targeted areas.

Q: What advantages does CYH 500 offer for structural repairs and waterproofing?

A: This grout provides high compressive strength (>45 MPa), significant elongation (>200%), and quick curing times, ensuring rapid and durable repairs. Its foam structure adapts to crack widths, while its low water absorption and strong adhesion deliver long-lasting waterproofing.

Q: When should CYH 500 PU Foam Epoxy Grout be used for optimal results?

A: For the best performance, use CYH 500 when surface and product temperatures are around 25C. It's ideal when rapid sealing and reinforcement are required, such as in active leak scenarios or urgent structural interventions.

Q: Where can CYH 500 PU Foam Epoxy Grout be effectively utilized?

A: CYH 500 is suitable for concrete structures, tunnels, basements, water tanks, and any site requiring leak sealing, crack injection, or structural waterproofing. Its adaptability makes it valuable for contractors and facility managers across various environments.

Q: What is the process for handling and storing CYH 500 PU Foam Epoxy Grout?

A: Store the product in unopened barrels (20 kg or 25 kg) in a cool, dry place for up to 12 months. Ensure the area is well-ventilated during application, and follow instructions to maintain efficacy and safety.

Q: What benefits does the single-component design provide?

A: The one-component formula eliminates the need for on-site mixing, reducing labor and minimizing error. This simplifies handling and application, saving time and ensuring consistent product quality.
